TENTAL - Trame aspect

Main features

With TENTAL, not only you can imagine the world you want, you can build it too.

Created to inspire architects, this curtain wall system offers creative freedom with sleek 50 and 60 mm profiles in horizontal or vertical lines. It enables a distinctive and impactful façade with minimal sightlines, blending interior and exterior spaces seamlessly. Combining aesthetics with performance, it features high recycled content, supporting circularity and easy disassembly.

Elevate your designs with a solution that brings light, openness, and sustainability, helping you craft a unique, standout architectural identity.

Versatile design

With a choice of horizontal or vertical lines, this system offers sleek 50 or 60 mm sightlines and various glazing options from 6 mm to 62 mm. Available in flat or faceted façades, it accommodates up to +/- 20° angles, delivering aesthetic flexibility while maintaining clean, modern lines.

Advanced performances

Featuring optimized load distribution with heavy-duty connectors and pins, this system supports large glazing panels up to 850 kg. Enhanced thermal performance is available on the horizontal or vertical line, while glazing up to 62 mm boosts both acoustic and thermal efficiency.

Ventilation comfort

Integrated concealed top hung windows offer opening options for natural ventilation while maintaining a sleek façade. With generous dimensions and smooth operation, they enhance comfort and functionality without compromising aesthetics.

Carbon-conscious solution

TENTAL integrates at least 75% recycled content and is 95% recyclable, reducing environmental impact. Its main component, Hydro CIRCAL® (at least 75% end-of-life aluminium) achieves a CO2 footprint of 1.9 kg CO2 eq/ kg Al.—up to 80% lower than the european average for primary aluminum.

Design

The finishes have been designed with the greatest attention to detail, offering a harmonious appearance.

Performances

	TENTAL 50	TENTAL 60
Air permeability
TT	AE 1200 Pa	-
MT	AE 1200 Pa	AE 1200 Pa
Water tightness
TT	RE 1200 Pa	-
MT	RE 1500 Pa	RE 1500 Pa
Resistance to wind pressure	Service 2000 Pa Security 3000 Pa	Service 2000 Pa Security 3000 Pa

Labels & Certifications

Reduced CO2 footprint

Using Hydro CIRCAL© aluminium (1.9 kg CO2e/kg of Al.) allows 80% reduction of CO2 emissions vs the European average for primary aluminium. Ask for your dynamic Environment Product Declaration (EPD).

75% recycled

Our solutions are made with at least 75% of recycled components including aluminium, EPDM, polyamide.

95% recyclable

Our solutions are 95% recyclable. When we design our products, we act for circularity by taking into account their disassembly and re-use at the end of their life.

Cradle to Cradle

TENTAL 60 has been certified Cradle to Cradle silver level to prove the green value of your product.

Options

Many possibilities thanks to a wide range of configurations.

Colours

to be filled locally
